UL94V-2 Black And Gray Elastic wire sleeve Halogen Free Environmentally Friendly Polyester (PET)

Elastic Wire Sleeve

UL94V-2 Wire Sleeve

Wire Sleeve Halogen Free

Place of Origin:

China

Brand Name:

Qiaoguang

Document:

Product Brochure PDF

Request A Quote

UL94V-2 Black And Gray Elastic wire sleeve Halogen Free Environmentally Friendly Polyester (PET)

Product Details

Material:

Halogen-free Environmentally Friendly Polyester (PET)

Operating Temperature: -40~ 85 ° C For Normal Use:

-40~ 85 ° C For Normal Use

Flame Retardant Grade:

UL94V-2

Color:

Black And Gray, Other Colors Can Be Made According To Customer Requirements

Melting Point:

245 ± 5 ℃

Product Certification:

Comply With ROHS And NFF16-101 Certification Standards

Customization:

Support

Packing:

Carton

Highlight:

Elastic Wire Sleeve

UL94V-2 Wire Sleeve

Wire Sleeve Halogen Free

Payment & Shipping Terms

Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

Carton,Negotiation

Delivery Time

2 days after receiving full payment

Payment Terms

L/C, T/T, Western Union,Paypal,ALiPay

Supply Ability

20000pcs

Black And Gray Elastic Net Sleeve -40~ 85 ° C For Normal Use

Get Best Price

Heat and Cold Resistant Wrapping Band Fire Resistant PE/ PP

Get Best Price

RoHS Halogen Free Non Toxic Wrapping Band Fire Resistant

Get Best Price

Fire Resistant Wrapping Band PE / PP Heat and Cold Resistant -40℃ ~85℃

Get Best Price

86-0519-86972990

Contact Now

Product Description

Elastic Net Sleeve

1. Material: halogen-free environmentally friendly polyester (PET)

2. Operating temperature: -40~ 85 ° C for normal use

3. Flame retardant grade: UL94V-2

4. Color: black and gray, other colors can be made according to customer requirements

5. Melting point: 245 ± 5 ℃

6. Product certification: Comply with ROHS and NFF16-101 certification standards.

7. Product features: easy to use, used for wire protection, good corrosion resistance, easy to wear, can be bent arbitrarily, and has good insulation and aesthetics.

8. How to use: Pinch both ends of the telescopic mesh tube with both hands and tighten it in the direction of the shaft diameter, and the diameter of the telescopic tube will be more than doubled. The relative arbitrariness of the number of guardrails within a certain range is another major feature of this product. The required length is intercepted by thermal cutting to ensure that the nozzle of the braided pipe is not loose.

Model Specifications	Bending diameter(mm)	Threading diameter(mm)		Packaging
Model Specifications	Bending diameter(mm)	min.(I)	max.(O)	Packaging
S-3	3	Φ2.4	Φ6.3	200M/roll
S-6	6	Φ3.2	Φ11	200M/roll
S-10	10	Φ6.3	Φ13	100M/roll
S-13	13	Φ8.2	Φ19	100M/roll
S-15	15	Φ10	Φ22	100M/roll
S-19	19	Φ13	Φ25	100M/roll
S-25	25	Φ16	Φ35	100M/roll
S-32	32	Φ19	Φ44	50M/roll
S-38	38	Φ24	Φ48	50M/roll
S-45	45	Φ32	Φ70	50M/roll
S-50	50	Φ38	Φ89	50M/roll
S-60	60	Φ50	Φ120	50M/roll
